Marantz CD60 CD Player Silver

Marantz CD60 CD Player Silver

CD PLAYER

With its modern style and The Most Musical Sound, CD 60 inspires listeners to discover new details in their favourite CDs. Iconic design for modern CD enthusiasts.

Unveil New Sounds in Classic CDs
CD 60 is for those who cherish their CD collections and who seek to discover new details upon every listen

Luxurious Design Matches The Most Musical Sound
Architectural design, modern materials, and intuitive operation make CD 60 as incredible to behold as to hear.

Pairs Beautifully with Marantz Amplifiers
Complimentary visual design plus compatible technology make CD 60 a natural companion to MODEL 40n, MODEL 30, or other Marantz amplifiers

Rich, Warm, and Spacious Sound
Expertly tuned by the legendary Marantz Sound Master for The Most Musical Sound. CD 60 is the CD player your cherished collection deserves.

Optimized HDAM Circuit
In the CD 60, the proprietary HDAM circuit has been further optimized from its previous version by placing the parts symmetrically on the audio board and creating a more direct signal path. This update improves the sound stage from the previous models in pursuit of The Most Musical Sound

High-Current Power Supply
The CD 60 power supply uses highspeed, high-current Schottky barrier diodes, higher value current storage capacitors and improved voltage regulators compared to predecessor models in this class. Oversize capacitors in the power supply improve current stability and reduced noise during highly demanding listening sessions.

 Plays Hi-Res Audio USB Sources

The CD 60 can play back MP3, WMA, AAC and WAV, FLAC HD, ALAC, AIFF (up to 192-kHz/24bit), and DSD (up to 5.6- MHz) files from a connected USB storage device.


General
Unit (W x H x D mm)     442 x 129 x 396
Net weight     7.5kg
Packaging Dimensions (W x H x D mm)     525×249×511
Panel Color     Available Colors: Silver/Gold and Marantz Black
Front (Center) Panel     Aluminum

Specifications
Frequency response     USB DSD: 2Hz - 50kHz (-3dB)
USB PCM: 2Hz - 50kHz (-1.5dB)
CD: 2Hz - 20kHz
Total Harmonic Distortion     USB DSD: 0.0006%
USB PCM 24bit: 0.0005%
CD: 0.0015%
Signal to Noise Ratio     USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 118dB
Dynamic Range     USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 101dB
Line Output Level     2.2Vrms
Headphone Output Level     28mW / 32 ohms
Power Consumption     38W
at Standby     0.3W

Audio Feature
HDAM     New HDAM + HDAM-SA2
Power Transformer     EI
Headphone Amp     High slew rate op-amp
+ HDAM-SA2
H/P Amp Gain Setting     Yes (Low / Mid / High)
Digital Filter     Filter 1, 2 Selectable
Connectivity / Playback Capability
CD Compatibility     CD / CD-R/RW / WMA / MP3 / AAC
Data Disc Compatibility     DSD / WAV / ALAC
Fixed Analog Output (RCA)     1 (Gold Plated)
Optical input / output (Maximum Support)     0 / 1
Coaxial input / output (Maximum Support)     0 / 1
Headphone Output     1
Remote Control Bus Terminal     Yes (RC-5 In / Out)
w/ External / Internal Select Switch
Flasher Input     Yes (U ver)
USB A     1 (Front)
Mass Storage Class
5V/1A
Support format     FAT 16/32
USB-A: FLAC / WAV / AIFF / ALAC / DSD     Yes / Yes / Yes / Yes
DSD Native Playback     Yes
USB Firmware Update     Yes

Easy to use
Remote Controller     System Remote
(Amp and CD Player Control)
Unit control (Button)     POWER, Play/Pause, Stop, Input, Open/Close, Fwd, Rev
Unit control (Knob)     1
Phones Level
Dimmer for Front Display     Bright / Dim / Dark / Off
Control with App via Network Player (Use Remote Control Bus)     Yes
Last Function Memory     Yes
Timer Play (Need external audio timer)     Yes
On/Off selectable in Menu
Auto Standby Mode     Yes
Other     Stereo RCA Cable x1
Remote connector cable x1
Accessory Box     Yes
Battery     Yes (AAA x2)
Power Cord     Yes
